擁有自主出口經營權、CE認證、ISO9001:2000認證
|
型 號 (Type) |
公稱 壓力 (KN) |
工作臺 長度 (mm) |
立柱 間距 (mm) |
喉口 深度 (mm) |
滑塊 行程 (mm) |
行程 次數 (次/分) |
最大開啟高度 (mm) |
主電機功率 | 機器重量 |
外形尺寸 L×W×H(mm) |
| WC67Y-40/2200 | 400 | 2200 | 1850 | 250 | 100 | ≥11 | 340 | 5.5 | 2,850 | 2260×1200×1900 |
| WC67Y-40/2500 | 400 | 2500 | 2055 | 250 | 100 | ≥11 | 340 | 5.5 | 3,500 | 2560×1200×1920 |
| WC67Y-63/2000 | 630 | 2000 | 1650 | 250 | 100 | ≥10 | 335 | 5.5 | 4,200 | 2160×1725×2200 |
| WC67Y-63/2500 | 630 | 2500 | 2050 | 250 | 100 | ≥10 | 335 | 5.5 | 4,800 | 2605×1725×2200 |
| WC67Y-63/3200 | 630 | 3200 | 2670 | 250 | 100 | ≥10 | 335 | 5.5 | 5,850 | 3300×1725×2355 |
| WC67Y-63/4000 | 630 | 4000 | 3300 | 250 | 100 | ≥10 | 350 | 5.5 | 6,500 | 4000×1725×2405 |
| WC67Y-80/2500 | 800 | 2500 | 2050 | 250 | 100 | ≥10 | 335 | 7.5 | 5,500 | 2605×1725×2355 |
| WC67Y-80/3200 | 800 | 3200 | 2660 | 250 | 100 | ≥10 | 335 | 7.5 | 6,500 | 3300×1725×2405 |
| WC67Y-100/2500 | 1000 | 2500 | 1950 | 320 | 140 | ≥8 | 385 | 7.5 | 6,500 | 2560×1320×2510 |
| WC67Y-100/3200 | 1000 | 3200 | 2650 | 320 | 140 | ≥8 | 385 | 7.5 | 8,000 | 3260×1320×2510 |
| WC67Y-100/3600 | 1000 | 3600 | 3000 | 320 | 140 | ≥8 | 385 | 7.5 | 8,500 | 3660×1320×2510 |
| WC67Y-100/4000 | 1000 | 4000 | 3200 | 320 | 140 | ≥8 | 385 | 7.5 | 9,000 | 4060×1320×2760 |
| WC67Y-100/5000 | 1000 | 5000 | 4200 | 320 | 150 | ≥8 | 420 | 7.5 | 11,000 | 5100×1740×2800 |
| WC67Y-125/3200 | 1250 | 3200 | 2680 | 320 | 150 | ≥8 | 370 | 7.5 | 8,500 | 3280×1820×2430 |
| WC67Y-125/3600 | 1250 | 3600 | 3000 | 320 | 150 | ≥8 | 370 | 7.5 | 9,500 | 3690×1740×2450 |
| WC67Y-125/4000 | 1250 | 4000 | 3280 | 320 | 150 | ≥8 | 370 | 7.5 | 10,000 | 4080×1825×2430 |
| WC67Y-160/3200 | 1600 | 3200 | 2640 | 320 | 200 | ≥6 | 470 | 11 | 11,500 | 3270×1625×2665 |
| WC67Y-160/4000 | 1600 | 4000 | 3300 | 320 | 200 | ≥6 | 470 | 11 | 12,500 | 4070×1625×2765 |
| WC67Y-160/4500 | 1600 | 4500 | 3300 | 320 | 200 | ≥6 | 470 | 11 | 14,000 | 4580×1930×2800 |
| WC67Y-160/5000 | 1600 | 5000 | 4100 | 320 | 200 | ≥6 | 470 | 11 | 15,000 | 5080×1930×3160 |
| WC67Y-200/3200 | 2000 | 3200 | 2800 | 320 | 200 | ≥3 | 465 | 11 | 13,000 | 3280×1930×2800 |
| WC67Y-200/4000 | 2000 | 4000 | 3300 | 320 | 200 | ≥3 | 485 | 11 | 15,200 | 4060×1750×2950 |
| WC67Y-200/4500 | 2000 | 4500 | 3300 | 320 | 200 | ≥3 | 465 | 11 | 18,000 | 4580×1930×2800 |
| WC67Y-200/5000 | 2000 | 5000 | 4100 | 320 | 200 | ≥3 | 465 | 11 | 21,000 |
5080×1930×3160 |
